順絡貼片鉭電容_貼片鉭電容10UF25V_貼片鉭電電容10UF16V

產品名稱：順絡貼片鉭電容_貼片鉭電容10UF25V_貼片鉭電電容10UF16V

所屬類別：順絡貼片鉭電容_貼片鉭電容10UF25V_貼片鉭電電容10UF16V

產品簡介：順絡貼片鉭電容,貼片鉭電容10UF25V,貼片鉭電電容10UF16V等產品咨詢電 ?話：0769-89917065

詳細介紹

順絡貼片鉭電容

順絡貼片鉭電容基本參數：

品牌	順絡	型號	10UF25V	介質材料	鉭電解
應用范圍	旁路	外形	方塊狀	功率特性	中功率
頻率特性	中頻	調節方式	固定	引線類型	無引線
允許偏差	±10（%）	耐壓值	25（V）	等效串聯電阻(ESR)	0（mΩ）
標稱容量	10（uF）	損耗	0.1	額定電壓	16（V）
絕緣電阻	0（mΩ）	溫度系數	0

貼片鉭電容10UF25V

貼片鉭電電容10UF16V

10UF16V貼片鉭電電容

順絡貼片鉭電容產品規格

TC312 TYPE
Capacitance (MF)	Case	Part Number	DCL (MA ) +25 C Max.	DF (%) +25 C 120 Hz Max.	ESR (m〇) +25 C 100kHz Max.
47	B	10311B476§0060070	30	8.0	70
68	B	10311B686§0060070	43	8.0	70
68	C	TC311C6860006D100	43	8.0	100
100	B	10311B107§0060070	63	8.0	70
100	C	TC311C1070006D045	63	8.0	45
150	B	10311B157§0060070	95	8.0	70
150	C	TC311C1570006D055	95	8.0	55
150	D	TC311D1570006D055	95	10.0	55
220	C	TC311C2270006D045	139	8.0	45
220	D	TC311D2270006D050	139	10.0	50
10V, +85C (8.0V @ +105C)
10	A	TC311A1060010D080	10	8.0	80
15	B	T0311B1560010口080	15	8.0	80
22	B	T0311B2260010口080	22	8.0	80
33	B	T0311B3360010口080	33	8.0	80
47	B	T0311B4760010口070	47	8.0	70
47	C	TC311C4760010D100	47	8.0	100
100	D	TC311D1070010D090	100	10.0	90
100	D	TC311D1070010D070	100	10.0	70
100	V	TC311V1070010D090	100	10.0	90
100	V	TC311V1070010D070	100	10.0	70
150	D	TC311D1570010D070	100	10.0	70
150	D	TC311D1570Q1QDQ55	150	10.0	55
16V, +85C (12.8V @ +105C)
10	B	T0311B1060016口100	16	8.0	100
15	B	T0311B1560016口100	24	8.0	100
22	B	T0311B2260016口090	35.2	8.0	90
22	C	TC311C2260 0160 080	35.2	8.0	80
33	C	TC311C3360 0160 080	52.8	8.0	80
33	D	TC311D3360 0160 070	52.8	10.0	70

Capacitance (MF)	Case	Part Number	DCL (MA) +2 5 C Max.	DF (%) +25 C 120Hz Max.	ESR (m〇) +2 5 C 100kHz Max.
16V, +85C (12.8V @ +105C)
33	V	TC312V33600160070	52.8	10.0	70
33	V	TC312V33600160060	52.8	10.0	60
33	V	TC312V33600160050	52.8	10.0	50
47	V	TC312V47600160070	75.2	10.0	70
47	V	TC312V47600160050	75.2	10.0	50
47	D	TC312D47600160070	75.2	10.0	70
47	D	TC312D47600160050	75.2	10.0	50
68	D	TC312D68600160070	108.8	10.0	70
68	D	TC312D68600160050	108.8	10.0	50
100	D	TC312D10700160070	160	10.0	70
100	D	TC312D10700160050	160	10.0	50
150	D	TC312D15700160070	240	10.0	70
150	D	TC312D15700160050	240	10.0	50
220	D	TC312D22700160070	352	10.0	70

Capacitance (MF)	Case	Part Number	DCL (MA ) +25 C Max.	DF (%) +2 5 C 120 Hz Max.	ESR (m〇) +2 5 C 100kHz Max.
220	D	TC312D22700160050	352	10.0	50
220	E	TC312E22700160070	352	10.0	70
330	E	TC312E33700160070	528	10.0	70
330	E	TC312E33700160060	528	10.0	60
330	E	TC312E33700160045	528	10.0	45
20V, +85C (16V @+105C)
10	B	TC312B10600200090	20	8.0	90
10	D	TC312D10600200090	20	10.0	90
15	B	TC312B15600200090	30	8.0	90
15	D	TC312D15600200090	30	10.0	90
22	B	T〇312B22600200100	44	10.0	100
22	D	TC312D22600200090	44	10.0	90
22	D	TC312D22600200070	44	10.0	70
22	V	TC312V22600200090	44	10.0	90
22	V	TC312D22600200070	44	10.0	70
